IsoTek SMART Alpha – Smart Power Distribution Unit

Programmable power management

The Smart Power Alpha combines an eightfold mains filter, which can be programmed via RS232 interface, LAN and WLAN, and a power strip in the smallest of spaces. Eight C14 IEC output sockets are available for connecting audio and home cinema components in just a 44.5 mm rackmount height unit. The connected devices are protected against current surges of up to 40,000 A and are supplied with electricity that has been cleaned of interference. Connection to the mains socket is via a standard IEC C15/16 connection. The Alpha reduces differential and common mode mains noise, with each output jack being independently filtered to avoid cross-contamination with the other connected devices. The Alpha also integrates with Control 4 and Crestron smart home systems.

FEATURES

– Naming of the individual output sockets with connected electronics
– Each output can be switched on and off individually
Remote reboot and sequential boot
– Programmable delay times between each output at start
– Independent control of outputs with date and time
– Combination of two or more units into named groups
– Power consumption overview and management
– Protection against power surges and voltage spikes
– Control via RS232, LAN and WiFi via secure online interface and dedicated codex for Control 4 and Crestron

TECHNICAL SPECIFICATIONS

NUMBER OF OUTPUTS 8
AVAILABLE OUTPUTS C14 IEC
POWER SUPPLY 10A IEC C20
OPERATING VOLTAGE 100-240 V / 50-60 Hz
CURRENT 10 A
(CONTINUOUS) POWER, TOTAL 2,300 W (@230 V) / 1,150 W (@115 V)
OVERVOLTAGE PROTECTION 40,000 A
RS232 CONTROLLER 1
NETWORK CONTROLLER (RJ45) 1
USER INTERFACE (GUI) Yes
